Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-399
Jaw crusher is combined with the secondary crushing equipment in the whole stone crushing line,like cone crusher and impact crusher. Due to their smaller physical size, jaw crushers are also ideal for tight spaces, such as underground mining and mobile crushing applications.
Common parameters of jaw crusher
| Model | Opening size(mm) | Max feeding size(mm) | Output adjust range(mm) | Production capacity(t/h) |
Power
(kw)
|
| PE250*400 | 250*400 | 200 | 20-50 | 5-20 | 15 |
| PE400*600 | 400*600 | 350 | 40-100 | 15-60 | 30-37 |
| PE500*700 | 500*700 | 425 | 50-100 | 40-110 | 45-55 |
| PE600*900 | 600*900 | 480 | 65-160 | 90-180 | 55-75 |
| PE750*1060 | 750*1060 | 630 | 80-140 | 110-320 | 90-110 |
| PE900*1200 | 900*1200 | 750 | 95-165 | 220-450 | 110-132 |
| PE1200*1500 | 1200*1500 | 1020 | 150-300 | 400-800 |
160-200 |
Working principle of stone jaw crusher motor drives the eccentric axis rotating throughthe belt pulley, so that the movable jaw approaches and leaves the fixed jaw cyclical,which makes the materials squeezed. rubbed. multi-roller crusher, etc. so that thematerials are crushed into small size, and then decline gradually, at last dischargefrom the discharging mouth
