Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-238
For pre-crushing before fine grinding, non-fine crushing, sharp-edged granules, and narrow granule distribution. With high-pressure roller mills products are produced with a precipitous granule distribution.
With high-pressure roller mills products are produced with a precipitous granule distribution.
Because only the outer particles of the material bed have contact with the surface of the rollers, milling that is almost contamination-free is possible.
Often used in the cases of medium-fine crushing of hard materials such as ceramics, minerals from 5 up to 9 on the MOHS hardness scale metals and metal alloys.
| Item | Detail Parameters | ||||||
| Model | HYY40 | HYY60 | HYY100 | HYY150 | HYY200 | HYY300 | HYY400 |
| Feeding Sizes | ﹤25mm | ﹤35mm | ﹤35mm | ﹤35mm | ﹤35mm | ﹤35mm | ﹤35mm |
| Throughput | 20-45t/h | 40-65t/h | 60-105t/h | 100-155t/h | 150-205t/h | 200-305t/h | 300-400t/h |
| Roller Dimension | 600*400mm | 800*500mm | 1000*600mm | 1250*600mm | 1500*700mm | 1750*700mm | 2000*700mm |
| Driving Power | 55kw | 90kw | 132kw | 200kw | 250kw | 315kw | 400kw |
| Output Sizes | ﹤5mm | ||||||
| Applicator Materials | Cobbles, iron ore, glass, ceramic, brittle materials, etc | ||||||
| Moisture | ﹤10% | ||||||
| Working Bearing Protection | Full time (Auto-control) | ||||||
| Overload Protection | Hydraulic (Auto-adjustment) | ||||||
| Central Oil Injection | Central greasing system | ||||||
