1-6t/h Biomass Pellet Machine for Pellet Making Plant
Hengyang Industry supplies complete turnkey project for biomass pellet production line.
The Biomass Pellet Machine of a biomass production line is the biomass pellet machine, hammer mill, rotary drum dryer, packing machine, belt conveyors and electrical control equipment etc.
Biomass Pellet Machine Available Raw Materials:
Wood, sawdust, wood chips, wood shavings, rice husk, peanut shell, palm nut, waste paper, leaf, coconut shell, cotton seed, bamboo dust, sugar cane, pulp, olive slag etc.
Biomass Pellet Machine Technical Details:
| Model | Capacity (t/h) | Power (kw) | Inner diameter of die | Pellet size (mm) | Dimension (mm) | Net weight (T) |
| HYW250 | 0.1-0.2 | 18.5 | 250 | Ø6,Ø8,Ø10 | 1300*1330*850 | 0.73 |
| HYW320 | 0.3-0.5 | 37 | 320 | Ø6,Ø8,Ø10 | 2100*1100*1400 | 1.2 |
| HYW350 | 0.5-0.8 | 55 | 350 | Ø6,Ø8,Ø10 | 2500*1100*1150 | 1.65 |
| HYW420 | 0.9-1.2 | 90 | 420 | Ø6,Ø8,Ø10 | 3000*1200*1470 | 2.8 |
| HYW520 | 1.3-1.8/1.8-2.5 | 132/160 | 520 | Ø6,Ø8,Ø10 | 3200*1300*1420 | 4 |
| HYW600X | 2.5-3 | 185 | 600 | Ø6,Ø8,Ø10 | 3000*1750*1810 | 4.5 |
| HYW660 | 3-4 | 200 | 660 | Ø6,Ø8,Ø10 | 3570*1800*1850 | 7.5 |
| HYW800 | 4-6 | 315 | 800 | Ø6,Ø8,Ø10 | 4300*1900*2040 | 11 |
Biomass Pellet Plant Production Process:
If the raw materials is log, wood chip or other big size materials. Generally, you should crush them at first. Because of the best size of raw materials in pelletizing is 3-6mm. So, based on different materials, wood chipper and hammer mill is necessary.
Drying system is a key equipment in making pellet. In other words, the moisture of the crushed materials is very important in processing. If the moisture is high, the pellet will be split at the head.
This is also a key equipment in making pellet. Our wood pellet mill is designed specially for pelletizing all kinds of the wood, such as hardwood and softwood, and we apply different ring die with different compression ratio, whose working principle is extruding between ring die and roller.
Help the pellet low down the temperature and to be sure to get high destiny pellet. Sifting system is for cleaning the powder in pelletizing to get the cleaning pellet for packing.
After cooling and sifting, packing is the last one job to do. In this part, generally, the client asked bulk bag and small bag. Bulk bag is 1Ton/Bag. The small bag is about 15-30kg/Bag.
