Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HYC003
Increased capacity with new crushing chamber design. Security sensor stops the system when the door is opened during maintenance. Lock systems prevent the machine body from closing down hazardously.
Impact Crusher Wear Parts:
Enhanced solid wear parts and liners.
Impact Crusher breaker Plates:
Two independent upper and lower breaker plates allow the required size of the end product to be easily obtained, with protection system against blocking.
Impact Crusher Features:
1. Optimized chamber design, high reduction rate
2. Option electronic sensing and feedback system avoids overload due to blockage
3. Two or three chamber configuration upon needs
4. Signature blow bar elongates hammer service life
Impact Crusher Technical Deatils:
| Model | Inlet size (mm) | Max. feed size (mm) | Rotor size (mm) | Capacity (t/h) | Power (kw) | Dimension (mm) | Weight (t) |
| PF-1416 | 1052×1652 | 400 | Ф1420×1600 | 280-350 | 355 | 4905×3154×2613 | 28 |
| PF-1520 | 1315×2040 | 400 | Ф1512×2000 | 350-450 | 400/450 | 3849×3422×3649 | 42 |
| PF-1620 | 1315×2040 | 400 | Ф1612×2000 | 450-550 | 500 | 3949×2520×3426 | 45 |
| PF-1820 | 1620×2040 | 500 | Ф1800×2000 | 550-700 | 630/710 | 4471×3250×4008 | 65 |
| PF-2024 | 1800×2430 | 800 | Ф2000×2400 | 800-1100 | 1120 | 4800×4740×4180 | 106 |
| PF-2325 | 1870x2510 | 1000 | Ф2300×2500 | 1000-1500 | 1000-1400 | 5100x4850x4900 | 128 |
| PF-2528 | 1980x2970 | 1200 | Ф2500×2800 | 1500-2100 | 1400-1600 | 6060x5940x5770 | 180 |
| PF-3036 | 2300x3300 | 1500 | Ф3000×3600 | 2200-3000 | 2000 | 6800x6500x6800 | 258 |
Note: Any change of technical data shall not be advised additionally.
