Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HYC002
All jaw crushers feature two jaws: one of which is fixed while the other moves. The working principle of jaw crushers is based on the reciprocating movement of the movable jaw that compresses and crushes the rock or ore between itself and the fixed jaw, as the material enters the zone between the jaws.
Jaw crushers are mainly used as primary crushers in aggregates production, mining operations and recycling applications. Their main purpose is to reduce rocks to smaller sizes for the next crushing stages.
Casting Shell Jaw Crusher Raw materials:Granite, limestone, basalt, shale, pebbles, bluestone, sandstone, carbide, iron ore, copper ore, steel slag, manganese ore, andesite, quartz, silica, gypsum, volcanic rock, marble, river stone, gravel, coal etc..
Casting Shell Jaw Crusher Capacity: 30-1050t/h
Casting Shell Jaw Crusher Max feeding size: 1200mm
Casting Shell Jaw Crusher Application: primary crushing applications in mining, aggregates, mineral processing, and recycling construction and demolition waste
Casting Shell Jaw Crusher Technical Details
| Model | Feed Opening (mm) | Max Feeding (mm) | Discharge Opening (mm) | Capacity (t/h) | REV (r/min) | Power (kw) | Motor Model | Machine Size (mm) |
| PE200×350 | 200×350 | 170 | 20-50 | 2-6 | 220 | 6-7.5 | Y160M-6/7.5 | |
| PE250×400 | 250×400 | 210 | 20-60 | 5-20 | 310 | 6-15 | Y180L-6/15 | 1450×1315×1296 |
| PE250×750 | 250×750 | 210 | 20-60 | 8-22 | 320 | 6-30 | Y225M-6/30 | |
| PE500×750 | 500×750 | 425 | 50-100 | 45-100 | 275 | 6-55 | Y280M-6/55 | 1890×1916×1870 |
| PE600×900 | 600×900 | 500 | 65-160 | 70-120 | 250 | 6-75 | Y315S-6/75 | 2520×1840×2303 |
| PE750×1060 | 750×1060 | 630 | 80-140 | 130-260 | 250 | 8-90 | Y315L1-8/90 | 2620×2302×3110 |
| PE900×1200 | 900×1200 | 750 | 95-165 | 220-380 | 200 | 8-130 | JR127-8/130 | 3789×2826×3025 |
| PE1000×1200 | 1000×1200 | 850 | 195-265 | 230-380 | 200 | 8-130 | JR127-8/130 | 3889×2826×3025 |
| PE1200×1500 | 1200×1500 | 1020 | 150-300 | 400-800 | 220 | 8-200 | YR355M4-8/200 | 4930×3150 |
