Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HYC001
All jaw crushers feature two jaws: one of which is fixed while the other moves. The working principle of jaw crushers is based on the reciprocating movement of the movable jaw that compresses and crushes the rock or ore between itself and the fixed jaw, as the material enters the zone between the jaws.
The moving jaw moves back and forward against the fixed jaw, and material fed from the top of the machine is compressed between the two, breaking it into smaller pieces. As the moving jaw moves away from the fixed jaw, the crushed material is discharged from the crusher at the bottom, with the size of the ejected material determined by the gap between the jaws.
Jaw Crusher Raw materials:Granite, limestone, basalt, shale, pebbles, bluestone, sandstone, carbide, iron ore, copper ore, steel slag, manganese ore, andesite, quartz, silica, gypsum, volcanic rock, marble, river stone, gravel, coal etc..
Jaw Crusher Capacity: 30-1050t/h
Jaw Crusher Max feeding size: 1200mm
Jaw Crusher Application: primary crushing applications in mining, aggregates, mineral processing, and recycling construction and demolition waste
Jaw Crusher Technical Details:
| Model | Feeder Opening Size(mm) | Max. Feeding Size (mm) | Discharging Opening Size(mm) | Capacity (t/h) | Motor Power (kw) | Overall Dimension (mm) |
| PE400x600 | 400x600 | 350 | 40-90 | 15-60 | 30 | 1700x1750x1680 |
| PE500x750 | 500x750 | 425 | 50-100 | 40-130 | 45 | 2150x1900x1950 |
| PE600x900 | 600x900 | 500 | 60-125 | 90-180 | 55 | 2500x2010x2350 |
| PE750x1060 | 750x1060 | 630 | 60-150 | 110-380 | 110 | 2630x2310x3110 |
| PE900x1200 | 900x1200 | 750 | 95-165 | 220-450 | 132 | 3720x2850x3250 |
| PE1000x1200 | 1000x1200 | 850 | 200-300 | 280-560 | 160 | 3820x2850x3250 |
| PE1200x1500 | 1200x1500 | 1020 | 150-300 | 400-800 | 220 | 3710x3446x4075 |
| PE1500x1800 | 1500x1800 | 1200 | 210-360 | 520-1100 | 280 | 5100x4700x4300 |
