Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-539
1. Using composite ceramic inner tank to ensure the purity of the powder
2. After sintering, the increment of metal magnetic foreign objects is ≤ 20 PPB
3. It is heated in the form of dynamic tumbling, without overburning and entrainment
4. Fully sealed structure ensures no leakage point in sintering process
5. Partition temperature control, temperature control zone is not less than 5
6. Continuous production, high productivity
| Project | Rotary kiln | Rotary cooler |
| Power | 380V×50Hz×3P×510kW | |
| Working power | 380V×350 kW(650°C) | |
| Output | 180~300 kg/Hr | |
| Specific gravity | 1.5g/cm³ | |
| Residence time | 180～360 min | 40~120 min |
| Design temperature | 900 ℃ | |
| Working temperature | 280～800 ℃ | |
| Product outlet temperature | 60℃ | |
| Cylinder size | DN800×12000 mm | DN800×6500 mm |
