Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-515
From logs & whole trees to pallet scrap and sorted C & D, HENGYANG has a solution for your grinding business, including technology for highly-abrasive materials like asphalt shingles or yard waste. These innovations allow you to diversify your grinding operation with simplicity and efficiency, maximizing the value of your grinding equipment.
Packed with exclusive maintenance simplifying features, Hengyang grinders keep you in control of your end product specifications and your production schedules. Changing teeth and screens is fast and easy. Routine maintenance areas are designed for quick access. Spend less time on maintenance and more time turning raw materials into commodities.
Technical Details:
| Type | HX826 | HX828 |
|---|---|---|
| Knife roll diameter(mm) | 650 | 800 |
| Fly-cutter quantity(piece) | 8 | 8 |
| Feeding port size | 1500×1500 | 1600×1500 |
| Crushed materials length | 30-50 | 30-50 |
| Production capacity(t/h) | 15-20 | 15-30 |
| Weight(t) | 9.8 | 11.2 |
| Main motor power(kw) | 75×2 | 110 |
| Knife roll rotating speed(rpm) | 590 | 590 |
| Boundary dimension(mm) | 3400×2500×3300 | 4000×2500×3300 |
