350t/h Stone Rotary Drum Washer Rotary Trommel Scrubber

Stone Rotary Drum Washer And Rotary Trommel Scrubber

Rotary gold trommel scrubber introduction:
The drum washing machine equipment is no different from other washing machines except for the different structure. The drum washing machine products have a very high degree of sand and stone cleaning. In many sand and gravel production lines, drum stone washing machines have also been widely used. Drum washing machine equipment is mainly used for desliming and screening operations of large amounts of sand and gravel used in construction sites, sand and gravel plants, prefabrication plants and hydropower sites, and can also be used for ore screening operations.


working principle of Rotary gold trommel scrubber introduction:

The cleaning cylinder of the drum washing machine is supported by four tugs, the motor drives the reducer, and the large and small gears drive the cleaning cylinder to rotate at low speed. Aggregate containing mud and stone powder is fed in from the feed port and enters the rotating drum. The wear-resistant rubber lining board with a certain angle installed in the cleaning drum is continuously lifted and dropped, moving from the feeding end to the discharging end. During the process, it circulates many times and is rinsed and washed by forward or reverse washing water. The cleaned aggregate is sieved and dehydrated by the discharge end cylinder screen and then discharged. The wastewater containing sludge flows out through the perforated baffle at the discharge or feed end.
Performance characteristics
1. The drum washing machine equipment has the characteristics of large feed size, so it is mainly used for desliming operations where artificial sand and sand aggregates are less than 80mm aggregates.
2. The aggregate mud content after washing by the drum washing machine equipment can be less than 0.5%, and the water content is less than 2%.
3. High integrity: Except for the finished material stacker belt conveyor, all systems are integrated in an overall frame, which not only ensures the integrity of the equipment, but also leaves moderate maintenance and inspection space.
4. The high integrity of the drum washing machine equipment is convenient and safe for storage at the construction site or transfer and transportation.
5. Work reliability: The stone washing system at the core of the drum washing machine adopts the mixing principle of the mixer. The raw materials are rolled and pushed by the continuous spiral blades and the friction between the materials in the mixing drum, which has a strong effect, natural and high reliability.
6. The drum washing machine equipment has a strong economical usability, and the storage hopper has a capacity of 8M3, so that the loader can reasonably arrange the loading time of the main equipment (such as the mixing station) and the stone washing machine to avoid the loading of the loader at different times. Frequent shifts between points and raw materials, and the width of the storage hopper mouth is greater than 3 meters, which also makes it easy for the loader to load materials and reduces labor intensity.
7. The drum washing machine equipment is also equipped with a water tank with the functions of waste water recycling, automatic compensation of clean water, rinsing when the finished material leaves the machine, and mud discharge. The water tank has a capacity of 2M3.
8. Finished stones can be stacked or put into warehouses or hoppers (for example: put into the batching machine stone hopper.
Technical parameters:
