Long time ago, almost all of them were hand-selected lithium ore. However, the manual separation method has great defects, such as high labor intensity, low production efficiency, etc. With the continuous development of mineral processing technology, the flotation method has gradually replaced the manual separation method to process lithium ore.
The treatment of lithium ore by flotation method has been applied abroad since the 1930s, but the treatment of lithium ore by flotation method in my country began in the late 1950s. There are two commonly used spodumene flotation methods, positive flotation and reverse flotation.
The magnetic separation method is usually suitable for lithium ore containing iron impurities, and the magnetic separation method is selected according to the magnetic strength of the iron material in the ore. The beneficiation mainly for iron-lithium ore can effectively improve the quality of lithium concentrate, and finally obtain higher-grade lithium concentrate.
This method is suitable for salt lake lithium mines, from which lithium salts are extracted. The process is to evaporate the brine on the drying field, precipitate the sodium salt and potassium salt, increase the concentration of lithium chloride to about 6%, and then enter it into the factory to convert the lithium chloride into lithium products.
Lithium ore beneficiation technology, after years of technical iteration and innovation, the current beneficiation method is very mature, it is difficult to achieve a high beneficiation recovery rate with a single beneficiation method, so we often use a combination of multiple processes.
| Final Products | Annual Output(t/a) | Spodumene Amount(t/h) | Main Equipment Model | ||
|---|---|---|---|---|---|
| Conversion Process | Acidification Process | Ball Mill | |||
| Lithium LiCO3 | 5000 | 5-6 | Roasting Kiln:φ2.8×50m; Cooler: φ2.6×40m | Acidification Kiln:φ2.8×50m; Cooler: φ2.4×35m | φ1.83×6.4m |
| Lithium LiCO3 | 10000 | 10-12 | Roasting Kiln:φ3.5×60m; Cooler: φ2.4×40m | Acidification Kiln:φ3.5×50m; Cooler: φ2.4×40m | φ2.4×8m |
| Final Product | Annual Output of Lithium(t/a) | Amount of Mixed Raw Materials (about 60% of Lepidolite) (t/h) | Main Equipment Model | ||
|---|---|---|---|---|---|
| Rotary Kiln | Cooler | Ball Mill | |||
| Lithium LiCO3 | 3000 | 15-18 | φ3.5×60m | φ2.5×23m | φ1.83×6.4m |
| Lithium LiCO3 | 5000 | 25-30 | φ4.2×72m | φ3×45m | φ3.2×13m |
1. Main equipment: Acidification mixer, rotary kiln, rotary cooler, Acidification kiln, raw ball mill, bag type dust collector and fan.
2. Rotary kiln diameter: 1.5-4.5m.
3. Calcination temperature: ~1250℃
4. Acidification temperature: ~350℃
5. The fuel of calcination:Natural gas, coal dust and coal gas
