Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9000
Model Number:
HC-141
Ball Mill Application:
Mining Industry : Used to grind various kinds of ores.
Ceramic Industry : Used to finish and grind various kinds of raw materials and cement.
Smelting Industry : Used to grind various kinds of slag.
Power generation : Used to grind coal for combustion use.
Chemical Industry : Used to grind coke, ilmenite, and others.
Food Industry: used for grinding additive materials.
Ball Mill Technical Details:
Overflow Type, Grate-discharge Type and Compartment type
| Size | Inside dia. Length of shell (mm) |
Ball charging amount (tons) |
Mill revolution (min-1) |
Power consumption (kW) |
Motor output (kW) |
Capacity (t/h) | |
| A | B | ||||||
| 1212 1515 |
1200×1200 1500×1500 |
2.05 4.15 |
32.0 29.0 |
16.5 35.8 |
18.5 37 |
1.5 3.5 |
1.3 3.1 |
| 1818 2121 |
1800×1800 2100×2100 |
7.4 11.7 |
25.3 23.0 |
65.3 106 |
75 110 |
6.6 11.0 |
5.8 9.6 |
| 2424 2430 |
2400×2400 2400×3000 |
17.6 22.0 |
21.4 21.4 |
167 209 |
190 220 |
18.0 22.4 |
15.8 19.6 |
| 2727 2733 |
2700×2700 2700×3300 |
25.4 31.0 |
20.1 20.1 |
250 306 |
260 340 |
27.5 33.7 |
24.1 29.6 |
| 3030 3036 |
3000×3000 3000×3600 |
35.0 42.0 |
18.8 18.8 |
350 420 |
375 450 |
39.5 47.3 |
34.6 41.5 |
| 3236 3242 |
3200×3600 3200×4200 |
48.0 56.0 |
18.0 18.0 |
484 565 |
510 600 |
55.5 65.0 |
48.7 57.0 |
| 3442 3648 |
3400×4200 3600×4800 |
63.5 81.5 |
17.5 16.6 |
655 845 |
700 900 |
75.5 99.0 |
66.0 86.0 |
| 3848 4051 |
3800×4800 4000×5100 |
91.5 108.0 |
16.2 15.8 |
960 1160 |
1000 1200 |
113.0 139.0 |
99.0 122.0 |
