Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-312
Depending on the type of grinding required, two types of ball movement are distinguished:
At the cataract movement balls are lifted higher and more balls are ejected from the surface at the top of the mill. These balls fall freely. Grinding takes place mainly because of the impact forces. Cataract movement is used for coarse grinding in the 1. compartment. Lifting liners in this compartment assist the cataract movement.
Cascade movement is used in the fine grinding compartment. The balls are carried up by friction and roll down at the surface. Grinding takes place mainly because of friction.
The movement of balls depends on:
| Wearing Part | Raw Material | ||
| Liner plate | ZGMn13 | ||
| Pinion | 35SiMn | ||
| Lifter blade | Q235A | ||
| Grate plate | ZGMn13 | ||
| Blind plate | ZGMn13 | ||
| Sieve plate | 1Cr8Ni9Ti | ||
| Bolt | Q235A |
