Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-293
Active carbon grinding machine is pre-disposal equipment for active carbon before kneading and granulating. Before kneading, active carbon will be grinded into powder by active carbon grinding machine. Then, under function of coal tar and binder, powder will become into certain shape. Hengyang active carbon grinding machine holds high capacity and good performance. Besides, cost for consumable components of active carbon grinding machine are cheap.
Advantage of Active Carbon Ball Mill
1,Active carbon grinding machine can grind active carbon particles to 200mesh or smaller powder so that to prepare for kneading, granulating and briquetting process.
2,Hengyang active carbon grinding machine holds superiority in terms of capacity and efficiency than other grinding machine. Besides high working efficiency, Hengyang active carbon grinding machine holds very long service life.
3,Owing to new structure, Hengyang active carbon grinding machine holds stable performance and low electricity consumption. It can be used for both batch production and continuous production work.
Technical Details of Active Carbon Ball Mill
| Model | Rpm r/min | Loading amount t | Feeding size mm | Output size mm | Capacity t/h | Motor power kw | Weight t |
| Φ900×1800 | 38 | 1.5 | 20 | 0.075-0.89 | 0.65-2 | 18.5 | 3.6 |
| Φ900×2100 | 38 | 2.7 | ≤20 | 0.075-0.83 | 0.7-3.5 | 22 | 3.9 |
| Φ900×3000 | 38 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | 4.5 |
| Φ1200×2400 | 32 | 3.8 | ≤25 | 0.075-0.6 | 1.5-4.8 | 45 | 11.5 |
| Φ1200×4500 | 32 | 7 | ≤25 | 0.074-0.4 | 1.6-5.8 | 55 | 13.8 |
| Φ1500×3000 | 27 | 8 | ≤25 | 0.074-0.4 | 44232 | 90 | 17 |
| Φ1500×4500 | 27 | 14 | ≤25 | 0.074-0.4 | 44262 | 110 | 21 |
| Φ1500×5700 | 27 | 15 | ≤25 | 0.074-0.4 | 3.5-8 | 132 | 24.7 |
| Φ1830×3000 | 24 | 18 | ≤25 | 0.074-0.4 | 44296 | 180 | 28 |
| Φ1830×7000 | 24 | 25 | ≤25 | 0.074-0.4 | 7.5-17 | 245 | 36 |
| Φ2200×5500 | 21 | 30 | ≤25 | 0.074-0.4 | 44491 | 370 | 48.5 |
| Φ2200×6500 | 21 | 31 | ≤25 | 0.074-0.4 | 14-26 | 380 | 52.8 |
| Φ2200×7500 | 21 | 33 | ≤25 | 0.074-0.4 | 16-29 | 380 | 56 |
| Φ2400×4500 | 21 | 30 | ≤25 | 0.074-0.4 | 8.5-60 | 320 | 65 |
| Φ2700×3600 | 20.6 | 39 | ≤25 | 0.074-0.4 | 12-70 | 400 | 91.3 |
| Φ2700×4000 | 20.7 | 40 | ≤25 | 0.074-0.4 | 12-80 | 400 | 94 |
| Φ2700×4500 | 20.7 | 48 | ≤25 | 0.074-0.4 | 12-90 | 430 | 102 |
| Φ3200×4500 | 18 | 65 | ≤25 | 0.074-0.4 | 12-100 | 800 | 137 |
| Φ3600×4500 | 17 | 90 | ≤25 | 0.074-0.4 | According to process | 850 | 158 |
| Φ3600×6000 | 17 | 110 | ≤25 | 0.074-0.4 | According to process | 1250 | 175 |
