Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-288
The batch ball mill is a kind of ball milling machine which discharges the material in one time according to the nature of the material. Different from continuous ball mill, batch type ball mill grinds powder by times and adopts intermittent operation. The batch mill is mainly used for the mixing and grinding of materials, with uniform product fineness and saving power. The grinding time can be adjusted according to the fineness of the grinding material. The batch ball mills can be used for both dry and wet grinding. They are mostly used for fine grinding of feldspar, quartz, ore, clay and other raw materials.
In order to meet the grinding properties of different materials, different ball mill liner types can be used on the batch type ball mill. Special lining can also reduce the possibility of mixing ferrous metals such as less steel, iron and manganese into raw materials.
The fineness of the grinding operation of the batch ball mill can reach 1000-16000 mesh, and the fineness can be controlled by the grinding time. The motor can be started with auto-decoupling and decompression to reduce the starting current. Its structure is divided into integral type and independent type.
The batch ball mill has the characteristics of less investment, energy saving and electricity saving, novel structure, simple operation, safe operation, stable and reliable performance, etc. It is suitable for mixing and grinding operations of ordinary and special materials. The user can select the appropriate type, liner and medium type according to the material specific gravity, hardness, yield and other factors. Of course, the batch dry ball mill or the batch wet ball mill can also be selected according to the nature of the processed material and its own situation. Please feel free to contact us for expert advice.
Performance Advantage Of Batch Ball Mill
The batch type ball mill has two compartments involved in grinding, can be used for coarse grinding and fine grinding of materials. It can improve the grinding precision and improve the quality of finished products.
The batch ball mill is easy to maintain. The inner liner, steel ball and other accessories of the two grinders are different. During the maintenance, the wear and other conditions in the two warehouses are different, and they can be repaired separately, which is very convenient.
The batch mill is more energy-saving and can save 40%-50% of electricity consumption than traditional ball grinding mill. Through the boosting effect of the power distribution circuit, the startup time is reduced by 3-5 minutes than before, and the production and grinding efficiency of the entire energy-saving batch ball mill are increased by 20% compared with before.
Technical Details of Batch Ball Mill
| Specification(mm) | Effective Volume(m3) | Maximum Charge(tons/time) | Rotate Speed(r/min) | Motor Power(kW) | Weight(t) |
|---|---|---|---|---|---|
| φ750×900 | 0.4 | 0.1 | 46 | 2.2 | 1.1 |
| φ900×1050 | 0.67 | 0.2 | 36 | 3 | 1.5 |
| φ940×1200 | 0.83 | 0.3 | 35 | 4 | 1.8 |
| φ1220×1230 | 1.43 | 0.5 | 30 | 5.5 | 2.2 |
| φ1600×1700 | 3.4 | 1 | 26 | 11 | 2.6 |
| φ1800×2100 | 5.3 | 1.5 | 23 | 15 | 3.8 |
| φ1900×2100 | 6 | 2 | 22 | 18.5 | 4.6 |
| φ2076×2600 | 8.8 | 3 | 22 | 30 | 6.5 |
| φ2500×2900 | 14.2 | 5 | 17 | 37 | 11 |
| φ2800×3000 | 18.5 | 8 | 16 | 55 | 15 |
| φ2800×3400 | 21 | 10 | 16 | 55 | 15.6 |
| φ3200×4000 | 32.2 | 15 | 13 | 90 | 23 |
| φ3200×5140 | 41.3 | 20 | 13 | 110 | 25 |
| φ3400×6350 | 57.6 | 30 | 12 | 132 | 36 |
| φ3600×7000 | 71.2 | 40 | 12 | 132 | 38 |
