Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-252
The spiral sand washing machine is suitable for washing, grading and removing impurities in metallurgy, building materials, hydropower, and other industries, and is used for washing of fine-grained and coarse-grain materials. It is suitable for sand for construction and gravel for road construction.
Spiral Sand Washing Machine Structure:
When the machine is working, the material goes into the input part. It will push the material to the output through the machine. Surface dust and impurity are removed when the material from the input part to the output part is pushed, mixed and washed. The final product goes out through the discharge outlet and the mud and impurity will go out through overflow part. This machine adopts a new type of external sealing structure and totally closed transmission structure, which requires maintenance in very few cases, and reduces the maintenance workload and cost of the equipment to the maximum extent.
Spiral Sand Washing Machine Technical Details:
| Model | Spiral Diameter (mm) | Spiral Length (mm) | Spiral Speed (m/rin) | Processing capacity (t/h) | Matching Motor (kw) | Dimensions (m) |
| XS0760 | 750 | 6000 | 18 | 15-30 | 7.5 | 7.6*1.4*1.5 |
| XS1075 | 1000 | 7500 | 18 | 30-50 | 15 | 9.6*2*2.2 |
| XS1275 | 1200 | 7500 | 16 | 50-80 | 18.5 | 9.8*2.1*2.2 |
| XS1575 | 1500 | 7500 | 16 | 80-120 | 30 | 10.3*2.3*2.2 |
| XS1590 | 1500 | 9000 | 16 | 120-150 | 30 | 11.8*2.4*2.2 |
