Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-245
Zhengzhou Hengyang Industry has been active in drying technology for more than 40 years. The Hengyang drum dryers are globally recognized as state-of-the-art drying technology.
Automatic and continuous. Vibrators, screw feeders, rotary airlocks, double flap valves, gravity chutes
Powders, granules, non friable agglomerates, large solid particles. Low to high feed rates
Electricity
Mostly Direct. Flow is co-current or countercurrent. Flow is a combination of through the bed, cross, co-current or countercurrent for rotation. Residence time Controllable.
Normally induced. Systems can have combustion, forced and induced draft fans for operation.
Cyclones, bag houses, scrubbers, Electrostatic precipitators. Systems require dust collection.
PLC, infrequently solid state controllers. System controls on discharge temperature. Can modulate energy and feed.
Electricity-Heating Sources Rotary Drum Dryer Technical Details
| Type | Spec | Dia of Roll | Length of roll | Gradient | Speed(rpm) | Weight(t) | Motor Power(kw) | Heating Power (KW) |
| HY600 | φ 0.6× 8 | φ 600 | 8m | 3-5 | 8 | 5.1 | 4/6p | 45 |
| HY800 | φ 0.8× 10 | φ 800 | 10 m | 3-5 | 7.2 | 6.9 | 4/6p | 60 |
| HY1000 | φ 1.0× 10 | φ 1000 | 10m | 3-5 | 6.73 | 7.5 | 5.5/6p | 90 |
| HY1200 | φ 1.2× 12 | φ 1200 | 12m | 3-5 | 5.8 | 13.1 | 11/6p | 120 |
| HY1500 | φ 1.5× 12 | φ 1500 | 12m | 3-5 | 4.8 | 22.3 | 15/6p | 150 |
| HY2200 | φ 2.2× 14 | φ 2200 | 14m | 3-5 | 3.2 | 52.8 | 30 | 200 |
| HY2400 | φ 2.4× 18 | φ 2400 | 18m | 3-5 | 3 | 73.3 | 37 | 300 |
| HY2800 | φ 2.8× 24 | φ 2800 | 24m | 3-5 | 2.59 | 97 | 75 | 400 |
