Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-233
| Specification | Output (t/h) | Rotating speed of cylinder(r/min) | Cylinder slope (%) | Inlet temperature | Slurry temperature | Moisture of slurry | Motor power (kw) | Weight (t) |
| Φ3.0×12 | 100-150 | 5.0 | 1.76 | 350℃ | 110℃ | 25-30% | 55 | 71.0 |
| Φ3.0×13 | 100-150 | 5.0 | 1.76 | 350℃ | 110℃ | 25-30% | 55 | 75.3 |
| Φ4.0×12 | 150-200 | 4.1 | 1.5 | 350℃ | 110℃ | 25-30% | 110 | 105 |
| Φ4.0×14 | 150-200 | 4.1 | 1.5 | 350℃ | 110℃ | 25-30% | 130 | 109.8 |
| Φ3.0×12 | 200-300 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 160 | 151 |
| Φ3.0×12 | 200-300 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 185 | 160 |
| Φ3.0×12 | 400-500 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 220 | 184 |
| Φ3.0×12 | 400-500 | 4.1 | 1.5 | 450℃ | 110℃ | 25-30% | 250 | 196 |
| Φ3.0×12 | 500-600 | 4.1 | 1.5 | 650℃ | 115℃ | 25-30% | 280 | 255 |
| Φ3.0×12 | 500-600 | 4.1 | 1.5 | 650℃ | 115℃ | 25-30% | 315 | 265 |
