Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-180
PRODUCT FEATURES
The intelligent production lines ensure the straightness, hardness, toughness and tensile strength of the bars which can meet the application of different types of rod mills. High strength, high wear resistant, no peeling and no deformation.
SIZE AND TOLERANCE
| Diameter(mm) | Length(mm) | Diameter Tolerance(mm) | Length Tolerance(mm) |
| Φ50-150 | 2000-6000 | -1.6-0.2 | -20-0 |
CHEMICAL COMPOSITION
| Grade | C(%) | Si(%) | Mn(%) | Cr(%) | Cu(%) | Mo(%) | P(%) | S(%) | Ni(%) |
| 45# | 0.42-0.50 | 0.17-0.37 | 0.5-0.80 | 0-0.25 | 0-0.25 | 0-0.30 | 0-0.035 | 0-0.035 | 0-0.30 |
| 60Mn | 0.57-0.65 | 0.17-0.37 | 0.70-1.0 | 0-0.25 | 0-0.25 | 0-0.30 | 0-0.035 | 0-0.035 | 0-0.30 |
| 65Mn | 0.62-0.70 | 0.17-0.37 | 0.90-1.0 | 0-0.25 | 0-0.25 | 0-0.30 | 0-0.035 | 0-0.035 | 0-0.30 |
| 40Cr | 0.37-0.45 | 0.17-0.37 | 0.50-0.8 | 0.80-1.1 | 0-0.25 | 0-0.30 | 0-0.035 | 0-0.035 | 0-0.30 |
| 42CrMo | 0.38-0.45 | 0.17-0.37 | 0.50-0.80 | 0.90-1.2 | 0-0.03 | 0.15-0.25 | 0-0.035 | 0-0.035 | 0-0.30 |
| ZWB-2 | 0.70-0.80 | 0.17-0.37 | 0.70-0.80 | 0.50-0.60 | 0-0.25 | 0-0.30 | 0-0.035 | 0-0.035 | 0-0.30 |
TECHNICAL SPECIFICATION
| Impact Value(J/㎝²) | Hardness(HRC) | Breakage Rate | Drop Times | Straightness | |
| 5-7 | 45-55 | ＜ 1% | ≥ 30 | 2/1000 | |
