Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HC-144
Counter-Current Rotary Dryers are more suitable for materials that must be dried to very low levels of moisture, where the last traces of moisture are difficult to remove, or where an elevated product temperature is desirable.
They are also used effectively as combined dryer / preheaters. However, since the final product is in contact with the gas at its highest temperature the counter-current dryer is often unsuitable for heat sensitive materials. Although this system can be more efficient, moisture which is to remain in the product, is not so readily controlled.
Counter-Current Rotary Dryers Features
Dry product is in contact with the gas at its highest temperature
The final product is in contact with the gas at its lowest temperature
Counter-Current Rotary Dryers Benefits
Suitable for materials that must be dried to very low levels of moisture, where the last traces are of moisture are difficult to remove, or where an elevated product temperature is desired. Often used as a combined dryer/preheater.
Enables the moisture content to be readily controlled
Counter-Current Rotary Dryers Process Flow Diagram
Counter-Current Rotary Dryers Technical Details
Diameter: 600mm to 3500mm
Length: 8000mm to 65 000mm
Methods of heating: Direct or indirect
Capacity: 500kg/h to 175t/h
Fuel: coal, natural gas, heavy oil, etc
Temp range: 200-700°C
Material: Carbon steel, Stainless steel, etc
Thickness: 8mm to 70mm
