Kaolin, or ‘china clay’ as it is commonly called, is a hydrated aluminum silicate crystalline mineral formed over many millions of years by the hydrothermal decomposition of granite rocks. Hydrous kaolin is characterized by its fine particle size, plate-like or lamellar particle shape, and chemical inertness. Hengyang Industry is a manufactured by the calcination of kaolin to form an amorphous pozzolanic white mineral additive for use in cement-based products. Calcined Kaolin is an anhydrous aluminum silicate produced by heating ultrafine natural kaolin to high temperatures in a kiln. The calcination process increases whiteness and hardness, improves electrical properties, and alters the size and shape of the kaolin particles.
Rotary Kiln Design Requirements
The following information is required to determine the tube OD, tube ID, tube length, tube rotation speed, the tube inclination angle, and the tube materials.
China Clay or Kaolinite Rotary Kiln is mainly calcinate kaolin and use in ceramic industry.
China Clay or Kaolinite Rotary Kiln Technical details:
|
Specification(m)
|
φ2.8/2.5×44
|
φ3×48
|
φ3.2×50
|
φ3.3×50
|
φ3.5×54
|
φ4×60
|
φ4.3×64
|
φ4.8×74
|
φ5.0×74
|
φ5.6×87
|
φ6.0×95
|
||
|
Capacity(t/d)
|
300
|
600-700
|
1000
|
1200
|
1500-1800
|
2500
|
3500
|
5000
|
6000
|
8000
|
10000
|
||
|
Slope of the kiln shell (%)
|
3.5
|
3.5
|
3.5
|
4
|
4
|
4
|
4
|
4
|
4
|
4
|
4
|
||
|
No.of supporters
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
3
|
||
|
Type of thrust roller
|
Mechanical
|
Mechanicalor Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
Hydraulic
|
||
|
Rotary speed of kiln
|
Main driving (r/min)
|
0.445-2.22
|
0.676-3.38
|
0.36-3.57
|
0.36-3.57
|
0.39-3.9
|
0.41-4.07
|
0.4-4.0
|
0.35-4
|
0.35-4
|
Max4.23
|
Max5
|
|
|
Auxiliary driving (r/min)
|
4.75
|
9.36
|
6.5
|
5.61
|
7.66
|
8.2
|
7.93
|
8.52
|
7.58
|
8.7
|
9.2
|
||
|
Main
driving |
Motor
|
Type
|
ZSN4-225-21
|
Z2-101
|
ZSN4-280-191B
|
ZSN4-280-191B
|
ZSN4-315-092
|
ZSN4-355-092
|
ZSN4-355-12
|
ZSN4-450-092Lp44
|
ZSN4-450-092
|
ZSN4-450-12
|
ZSN4-500-092
|
|
Rated power(kw)
|
55
|
100
|
160
|
160
|
220
|
315
|
400
|
630
|
710
|
800
|
950×2
|
||
|
Seed regulation
Range(r/min) |
～1000
|
～1500
|
1500
|
1500
|
1000
|
1000
|
100-1000
|
1500
|
87.5～1000
|
100～1000
|
100～1000
|
||
|
Rated voltage(V)
|
440
|
220
|
440
|
440
|
440
|
440
|
440
|
660
|
600
|
600
|
600
|
||
|
Reducer
|
Type
|
ZS145-1-1
|
ZS145-1-1
|
ZSY-450-40-V
|
ZSY450-40
|
NZS995-28VIBL
|
YNS1110-22.4VBR
|
YNS1400-3105VIBL
|
JH710C-SW305-40
|
JH280C-45
|
JH900C-SW305-25
|
JH900C-SW305-28
|
|
|
Total speed ratio
|
49-63
|
50
|
40
|
40
|
28
|
22.4
|
31.5
|
42.226
|
28
|
23.901
|
26.646
|
||
|
Auxiliary
driving |
Motor
|
Type
|
Y122M-4
|
Y160M-6
|
Y160M-4B
|
Y160M-4
|
Y200L1-6
|
Y180L-4
|
Y200L-4
|
Y225M-4 lp44
|
Y250M-4
|
Y280M-4
|
Y315M1-4
|
|
Rated power (kw)
|
4
|
7.5
|
15
|
11
|
18.5
|
22
|
30
|
55
|
55
|
90
|
132
|
||
|
Rated rotary
Speed (r/min) |
1440
|
970
|
1460
|
1460
|
970
|
1470
|
1470
|
1480
|
1480
|
1480
|
1490
|
||
|
Rated voltage(v)
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
380
|
||
|
Reducer
|
Type
|
ZL35-16
|
ZL35-7-1
|
ZSY160-31.5-‖
|
ZSY355-31.5
|
ZSY355
|
YNS440-45‖R
|
YNS497-45ZC
|
JH220C-SW302-28
|
JH280C-45
|
ZSY400-35.5-︱
|
ZSY450-35.5-︱
|
|
|
Total speed ratio
|
40.44
|
14
|
31.5
|
31.5
|
45
|
45
|
45
|
28
|
45
|
35.795
|
35.795
|
||
|
Totalweight (excluding refractory brick)(t)
|
177
|
213
|
280.6
|
317
|
341
|
434
|
562
|
854
|
885
|
1201
|
1580
|
||
