Vibrating Feeder for Rock Crushing Plant
Profile
ZSW series round vibratory feeder is the latest super short linear vibration feeder, which designed by hengyang company to transport bulk material evenly to coarse crusher in crushing and screening station. The series of products have complete specifications, firm structure, impact resistance, and reliable operation. In order to ensure continuous and uniform feeding for the crusher, the material can be sifted effectively, which makes the system more economical and reasonable in configuration. It is necessary equipment for crushing and screening.
Technical Details
| Model | Max feed size (mm) |
Processing capacity (t/h) |
Motor power (kw) |
Dimensions (L*W*H)mm |
Theoretical weight (Ton) |
| GZD300×90 | 500 | 40~150 | 2×2.2 | 3000×1655×1630 | 1.9 |
| GZD370×100 | 700 | 150~300 | 2×3.2 | 4250×1874×1130 | 3.5 |
| GZD430×120 | 800 | 200~400 | 2×5.5 | 4500×2000×1600 | 4 |
| ZSW380×96 | 500 | 100~160 | 11 | 3882×2209×1844 | 4.35 |
| ZSW490×96 | 500 | 120~240 | 15 | 4957×2277×1757 | 5.4 |
| ZSW490×110 | 580 | 200~400 | 15 | 4957×2531×1757 | 6 |
| ZSW590×110 | 600 | 250~450 | 22 | 6000×2531×1757 | 6.4 |
| ZSW600×130 | 750 | 400~560 | 22 | 6178×2581×2083 | 8 |
| ZSW600×140 | 800 | 400~600 | 37 | 6178×2832×2083 | 8.5 |
