Place of Origin:
China
Brand Name:
hengyang
Certification:
ISO9001
Model Number:
HYD010
Silica Sand Rotary Dryer is also known as rotary drum sand dryer. For the drying of silica sand , the rotary dryer is used widely, and usually it is single drum sand dryer and triple-pass drum sand dryer.
◆ As the moisture of silica sand is surface water, then in order to enhance the heat efficiency and processing capacity, we need to increase the contact area between silica sand and hot air as much as possible. Our triple-pass drum silica sand dryer achieves this aim perfectly. For one time drying, the silica sand Rotary dryer can dry the silica sand to be below moisture 1% directly.
Structure of Silica Sand Rotary Dryer :
Drum, gear, ring, carrier roller, air pipe, high pressure draught fan, reducer machine, chimney, cyclone dust catcher, 40mm thickness heat insulating layer, feeder, electric control box, belt conveyor, etc.
For Customized Silica Sand Rotary Dryer, please supply more information as follows:
--- Input moisture content (%) of wet silica sand ?
--- Output moisture content (%) of dry silica sand ?
--- Input capacity (ton per hour) ?
--- Prefered fuel such as waste wood, coal, diesel, or natural gas, etc ?
--- Other special requirements if have ?
Technical Details of Silica Sand Rotary Dryer :
|
Fuel: coal, natural gas, heavy oil, etc Methods of heating: Direct or indirect
|
Specifications Diameter: 600mm to 3500mm Length: 8000mm to 65 000mm Capacity: 500kg/h to 175t/h Temp range: 200-700°C Material: Carbon steel, Stainless steel, etc Thickness: 8mm to 70mm |
