Place of Origin:
China
Brand Name:
Hengyang
Certification:
ISO9001
Model Number:
HL02
Rubber Mill Liners (ball mill rubber liner) are chosen for most Primary, Secondary and Tertiary Ball Mills. And in many cases rubber components are best suited for specific areas in AG and SAG mills.
Hengyang Industry has supplied complete rubber linings in some of the largest ball mills at 3.8 meters in diameter.
Ball Mill Rubber Liner Technical Details:
Hardness: 70
Tension Strength: 175kg/cm2
200% Tensile Stress:153 Kg/cm2
Akron abrasion: 0.18 M3/1.16KG
Permanent Set: 15%
Solid elasticity: 44.5%
Tension Power; 17.2MPa
Breaking Strength: 140 kg/cm2
Maximum elongation tensile:378%
Ball Mill Rubber Liner Features:
LOWER COST
These are very cost effective as COST PER TON OF ORE GRIND IS LOWER.
LESS MAINTENANCE
Rubber Mill Liners are engineered to resist abrasion, increasing the interval between maintenance intervals.
REDUCED NOISE
Rubber Mill Liners REDUCE THE NOISE LEVEL to safer levels by absorbing impact against the shell
NO LEAKAGE
Rubber mill liners seal to the shell eliminating slurry leakage from the mill.
